Acra Horizontal Bandsaw BS-250VS

Acra Horizontal Bandsaw BS-250VS is a Acra Machinery product in the Band Saws collection.

Product Details

• Blade Speed: 82~259 FPM
• Bed Height: 23 1/2"
• Swivel Base: 60~90°
• Voltage: 220/440V AC/3PH
• Features
• Variable Speed / Swivel Head (Miter)
• Horizontal Bandsaws
• Large Handwheel And Build-In Gauge For Easy Blade Tensioning
• Built In Coolant, And Coolant Is Distributed Through The Blade Guides
• Carbide Tungsten Blade Guide Supported By Bridge Type Portable Frame
• Blade Brush Is Build-In And Self Propelled
• Quick Positioning Clamping Vise With Fully Adjustable Jaws The Rapid Action Vice
• With 90 To 60 Full Mitering
• Removable Cip Tray For Easy Clean Up
• Fully Adjustable Hydraulic Down Feed With Separate On/Off Valve
• Heavy Duty Cast-iron Construction
• Low Voltage Control With Overload Protection
• Centralized Control Panel
• Standard Coolant
• Specifications
• Capacity (Round) 90°: 10"
• Capacity (Round) 45°: 8 1/2"
• Capacity (Rect.) 90°: 10" x 15"
• Capacity (Rect.) 45°: 10" x 9 1/2"
• Throat Depth: 10 1/2"
• Blade Size: 1" x 0.35" x 135"
• Main Motor: 2 HP
• Floor Space: 68" x 30" x 44 1/2"
• Weight: 1060 LBS
• Gross Weight: 1190 LBS

Specifications

• Manufacturer: Acra Machinery
• SKU: BS-250VS
• Shipping Method: LTL Freight
• Weight: 1,150 lb
• Country of Origin: Taiwan
