Baileigh Industrial 220V Single Phase 8ft Manual Magnetic Sheet Metal Brake BB-9616M BA9-1231891
$4,817.50Current price is: $4,817.50.
- Thickness (SS): 16 ga. (20 ga.)
- Clamping Force: 6 ton
- Bend Angle: 0 – 180°
- Max. Clamping Bar Lift: Unlimited
Baileigh Industrial 220V Single Phase 8ft Manual Magnetic Sheet Metal Brake BB-9616M BA9-1231891 is a Baileigh Industrial product in the Sheet Metal Brakes collection.
Product Details
- Thickness (SS): 16 ga. (20 ga.)
- Clamping Force: 6 ton
- Bend Angle: 0 – 180°
- Max. Clamping Bar Lift: Unlimited
- Description
- An industry breakthrough, this electromagnetic box and pan brake lets you make fully-enclosed ducts—impossible on a traditional box brake.
- Recommended for:
- HVAC shops, industrial art shops, and general sheet metal fabrication shops.
- Making ductwork, triangles, alternate bends on varying planes, round items such as scrolling applications, and much more.
- *****IMPORTANT INFORMATION!*****
- To achieve proper performance and prevent damage to the machine, the power supplied must be 220VAC +/-5% (209VAC to 231VAC). Failure to comply will damage the machine and void the warranty.
- Features
- Same open-ended design as Baileigh’s BB-4816M, but with twice the length (4 feet more)!
- Bending length of 8 feet (96”).
- 16 gauge mild steel maximum capacity.
- Maximum bend angle of 180°.
- Industrial-strength magnet clamps the material between the work surface and the bending “clamp bar” or finger.
- Requires 220-volt single-phase power for the magnet.
- This electromagnetic sheet metal brake can bend boxes or pans to almost any depth, since it isn't reliant on conventional finger depths.
- Baileigh covers this magnetic sheet metal brake with a 1-year parts warranty.
- Baileigh keeps most replacement parts in stock for speedy deliveries.
- Includes lifetime technical support by phone. Whenever you need troubleshooting or project advice, you can call a knowledgeable Baileigh rep.
- Specifications
- Item Number: BB-9616M-V2
- Power: 220V / 1-phase
- Shipping Weight: 1,070 lbs.
- Length: 96”
- Things to Know Before Purchase: To achieve proper performance and prevent damage to the machine, the power supplied must be 220VAC +/-5% (209VAC to 231VAC). Failure to comply will damage the machine and void the warranty.
- Shipping Dimensions: 109” x 45” x 21”
Specifications
- Manufacturer: Baileigh Industrial
- SKU: BA9-1231891
- UPC: 731325856101
- Shipping Method: Flatbed
- Weight: 2,756 lb
- Dimensions: 109 × 45 × 21 in
- Country of Origin: China
- Warranty: 1 Year (Parts)
| Weight | 2756.0 lbs |
|---|---|
| Dimensions | 109.0 × 45.0 × 21.0 in |
| Brand | Baileigh Industrial |
