Clausing Kalamazoo 230V Three Phase 24” Double-Column Variable-Speed Automatic NC Horizontal Bandsaw H2430NC

Clausing Kalamazoo 230V Three Phase 24” Double-Column Variable-Speed Automatic NC Horizontal Bandsaw H2430NC is a Clausing Industrial product in the Band Saws collection.

Product Details

• Blade Speeds (variable): 66 – 328 fpm
• Blade Size: 2” x 0.06” x 283”
• Feed Length/Index: 19.7”
• Bed Height: 23.6”
• Description
• This Double Column Automatic Horizontal Bandsaw is designed for rugged production use and it offers high production output and heavy-duty performance in fully automatic operation.
• A powerful drive motor provides the power and the Smart NC-20 technology is programmable for different jobs.
• Three phase refers to three individual lines that connect to and run voltage through the motor. Each line alternates in a sequence as it reaches its voltage peak. This provides for a more stable flow of voltage and more horsepower to the machine.
• Features
• Oversized precision ground, large dual columns
• Cross link connecting two columns for enhanced structural strength
• Specially designed gearbox for high lateral pressure
• Heavy duty inverter blade drive system
• LED speed indicator
• Cam lock carbide blade guides with bearing guides
• Two additional guides to support the blade from the top
• Automatic hydraulic blade tensioning device
• Integral coolant system
• Synchronized power driven blade brush
• Smart NC-20 Control
• Ergonomically located independent control station
• Precision feed pressure & feed rate dual valve system
• “Last cut” or “keep on” selector
• Split vise jaws
• Full stroke ductile cast iron vise
• NC Controlled multiple indexing for long cutting lengths up to 650”
• Ductile cast iron vises with replaceable hardened wear plates
• Proximity switch for sensing blade slippage or breakage
• Blade “clip” device for easy blade change
• Discharge roller workbed with built-in coolant return
• Additional flushing blade
• Bi-metal saw blade
• Toolbox, leveling pads, and an additional wire brush
• Operation & parts manual
• Specifications
• Machine Style: Automatic
• Drive Type: Inverter Controlled Infinitely Variable Speed
• Hydraulic Pump Motor: 2HP
• Hydraulic Oil Capacity: 10.5 gallons
• Blade Tension: hydraulic
• Coolant: recirculating
• Coolant Capacity: 22.5 gallons
• Electrical Requirements: 230V Three Phase 7.5HP
• Machine Dims: 123” x 43” x 82”
• Approx Weight: 5,016 lbs
• Cutting Capacities @ 90°
• Round: 24.4”
• Square: 24.4” x 24.4”
• Rectangular: 24.4” x 30”
• Optional Add-Ons
• Other voltages available (please contact a sales rep for more info)
• HD Roll Tables, Various Sizes
• Vise Pressure Regulator (VP24NC)
• Chip Conveyor (CM2401NC)
• Hydraulic Bundle Clamps (CM2402NC)
• Motor Load Meter (H24-AMP)
• Stock Height Detector (H24-SHD)
• Blade Deviation Detector (H24-BDD)
• Automatic Wedging Resistance (H24-AWR)
• SAWZIT 1 Gallon (CSR1)
• SAWZIT 5 Gallon (CSR5)

Specifications

• Manufacturer: Clausing Industrial
• SKU: H2430NC
• Shipping Method: Flatbed
• Weight: 11,904 lb
• Dimensions: 165 × 87 × 99 in
