Edwards 60 Ton Shop Press with PLC and Portable Power Unit 230V, 1Ph HAT8060
$19,723.92Current price is: $19,723.92.
- 20' quick-connect hoses for simple "plug & play" operation
- Accepts a variety of standard and custom tooling
- Electric foot pedal with integrated jog control
- Hydraulic-assist adjustable work table heights to maximize operator safety includes lift chains and bracket
Edwards 60 Ton Shop Press with PLC and Portable Power Unit 230V, 1Ph HAT8060 is a Edwards Manufacturing product in the Hydraulic Presses collection.
Product Details
- 20' quick-connect hoses for simple "plug & play" operation
- Accepts a variety of standard and custom tooling
- Electric foot pedal with integrated jog control
- Hydraulic-assist adjustable work table heights to maximize operator safety includes lift chains and bracket
- Magnetic PLC control box mounts anywhere on the shop press for user performance and comfort
- This 60 Ton Shop Press includes a Programmable Logic Control (PLC) to maximize your efficiency with shorter cycle times – over a 50% time savings. With a large work table area, this Shop Press accepts both standard and custom tooling to press bearings, bend metal or straighten a part. The rolling cylinder, open-sided design, and electric foot pedal make this machine simple to use. G19
- Open-sided design allows longer material to pass through the frame
- Programmable Logic Control (PLC) allows operators to create repeatable actions, improving efficiency
- Requires an Edwards Ironworker with PowerLink System or a Portable Power Unit to operate (included)
- Rolling cylinder provides maximum adaptability
- Specification: Value
- Minimum Ram Speed (In./Sec): 0.33
- Minimum Return Speed (In./Sec): 0.456
- Stroke (In.): 12-1/4
- Work Table (In.): 39-1/4 x 42
- Weight (Lbs.): 2300
- Rating (Tons): 60
- Product Dimensions (In.): 48 x 54 x 86
- Net Weight (Lbs.): 2300
- Gross Weight (Lbs): 2300
- Height: 122.0000
- Length: 72.0000
- Weight: 1900.0000
- Width: 102.0000
Specifications
- Manufacturer: Edwards Manufacturing
- SKU: ED9-HAT8060
- UPC: 731325714258
- Shipping Method: LTL Freight
- Weight: 2,300 lb
- Dimensions: 72 × 102 × 122 in
- Country of Origin: United States of America
| Weight | 2300.0 lbs |
|---|---|
| Dimensions | 72.0 × 102.0 × 122.0 in |
| Brand | Edwards Manufacturing |
