GMC Machinery 10HP 220V 20” x 60” Gap Bed Metal High Speed Lathe GML-2060
$16,802.50Current price is: $16,802.50.
- Max. swing over bed: 20"
- Max. length of workpiece: 60"
- Max. swing over cross slide: 12-1/2"
- Max. Swing in gap: 29-1/8”
GMC Machinery 10HP 220V 20” x 60” Gap Bed Metal High Speed Lathe GML-2060 is a GMC Machinery product in the Lathes collection.
Product Details
- Max. swing over bed: 20"
- Max. length of workpiece: 60"
- Max. swing over cross slide: 12-1/2"
- Max. Swing in gap: 29-1/8”
- Description
- If you're looking to replace your old workhorse, let GMC Machinery introduce their Taiwanese quality Gap Bed. Their lathes offer the convenience of turning larger stock with the removable gap in bed.
- Features
- ISO 9001 certified
- Large spindle bore 3-1/8”
- Heavy Duty spindle D1-8
- 4-way rapid traverse on the carriage longitudinal and cross
- Heavy Duty guideway width 12”
- Heavy Duty main motor 10HP
- 16 spindle speeds from 25-1,800 rpm, 12 speeds
- 60 kinds of inch threads, and 41 kinds of metric threads
- Threading and feeding rate change without changing gears
- Spindle is balanced, hardened and precision ground
- Spindle is supported at 3-point by high precision bearings
- All gears and shafts are hardened and precision ground
- Guideways induction hardened and precision ground
- Automatic lubrication system in headstock and feed box
- One year industrial warranty for parts
- Standard Equipment
- Free Taper turning attachment, , installed
- Free SINO DRO, installed
- Automatic kick-out longitudinal carriage stop system
- 10” 3-jaw chuck with top reversible jaws, direct mount
- 12” 4-jaw chuck, direct mount
- 14” Face plate
- 1/2”-6” steady rest with roller jaws
- 3” follow rest
- Removeable gap
- 4-way tool post
- Foot brake
- Halogen work light and coolant system
- Full length splash guard
- Dead centers
- Thread chasing dial
- Tool box and leveling pads
- Specifications
- Width of Bed: 12"
- Effective length in gap to spindle: 6"
- Effective length in gap to chuck jaws: 3-1/2"
- Spindle bore: 3-1/8" | D1-8
- Taper of spindle center: M.T. #7
- Spindle speeds: 25-1,800 rpm / 12 steps
- Longitudinal feeds: 0.0011-0.063 IPR, 42 kinds
- Cross feeds: 0.0003-0.018 IPR, 42 kinds
- Inch threads: 2-112 TPI, 60 kinds
- Metric threads: 0.1-14 mm , 41 kinds
- Diametral Pitch threads: 4-112DP , 50 kinds
- Module threads: 0.1-7mm, 34 kinds
- Max. travel of top slide: 5"
- Max. travel of cross slide: 11-1/4"
- Spindle length w/o chuck: 17-1/2"
- Leadscrew length X TPI: 1-1/4" x 4 TPI
- Diameter of tailstock quill: 2-3/8”
- Max. travel of tailstock quill: 5-1/8”
- Taper of tailstock quill center: MT4
- Main motor: 10HP, 220V/35A or 440V/20A, 3 phase
- Coolant pump: 1/8 HP, 220V, or 440V, 3 phase
- Net weight: 5,750 lbs.
- Overall dimensions (L x W x H): 108" x 43" x 59"
- Options
- 5-C Hand lever type collet closer, free install
- 33 pc 5C collet set, from 1/16”-1-1/16” by 32nd, Part # 900-0014
- China ALORIS type QC tool post set # 900-0051-300, 6 pcs
- Live Center # 900-0050-04
- 3/4” to 10-1/2” large steady rest with roller jaws
- *This model does not work with a phase converter*
Specifications
- Manufacturer: GMC Machinery
- SKU: GML-2060
- Shipping Method: Flatbed
- Weight: 5,950 lb
- Dimensions: 113 × 48 × 64 in
- Country of Origin: Taiwan
- Warranty: 1 Year (Parts)
| Weight | 5950.0 lbs |
|---|---|
| Dimensions | 113.0 × 48.0 × 64.0 in |
| Brand | GMC Machinery |
