Jet E-1236VS With Collet Closer 892301
$10,325.00Current price is: $10,325.00.
- 4-Position Carriage Stop
- Chuck guards are standard equipment on all ELITE lathes for increased safety
- Front facing chip pan allows easy chip removal from the front of the machine
- Hardened and ground gears in headstock reduce vibration and deflection
Jet E-1236VS With Collet Closer 892301 is a JET product in the Lathes collection.
Product Details
- 4-Position Carriage Stop
- Chuck guards are standard equipment on all ELITE lathes for increased safety
- Front facing chip pan allows easy chip removal from the front of the machine
- Hardened and ground gears in headstock reduce vibration and deflection
- Integrated locking tool cabinet in stand on 12" Lathe
- Compact, powerful, perfection. Elite EVS lathes pack large features into compact footprints that make them perfect for schools, small shops, and engineering labs. Featuring certified Meehanite® castings, an electro-magnetic brake, three jaw chuck, ball bearing-mounted steady and follow rests, and CNC Style Lighting with enclosed splash guard, these lathes are truly Elite! CSA/CUS Certified.
- Inverter drive system provides infinitely variable spindle speeds
- LED RPM readout allows for precise turning speeds
- Two speed gearbox allows low speeds from 40-365 RPM to high speeds from 165-2000 RPM
- Specification: Value
- Size: 12 x 36
- Style (Type): ELITE EVS
- Swing Over Bed (In.): 12
- Swing Over Cross Slide (In.): 7-5/16
- Swing Through Gap (In.): 17-1/2
- Length of Gap (In.): 9-1/2
- Spindle Bore (In.): 1-9/16
- Spindle Mount: D1-4
- Weight (Lbs.): 1212
- Range of Spindle Speeds (RPM): 0 – 2,000
- Spindle Taper with Sleeve: MT-5
- Number of Longitudinal and Cross Feed Rates: 50
- Range of Longitudinal Feeds (IPR): 0.0016 – 0.046
- Range of Cross Feeds (IPR): 0.0005 – 0.015
- Number of Inch Threads: 34
- Range of Inch Threads (TPI): 2 – 56
- Number of Metric Threads: 33
- Range of Metric Threads: 0.5 – 12
- Max Tool Size (In.): 1/2 x 1/2
- Compound Slide Travel (In.): 3-1/2
- Motor (HP): 2HP, 230V,3ph
- Tailstock Spindle Travel (In.): 4
- Taper in Tailstock Spindle: MT-3
- Steady Rest Capacity (In.): 1/4 – 2-1/2
- Width of Bed (In.): 7-1/2
- Overall Dimensions (L x W x H) (In.): 71 x 30 x 60
- Drive: EVS
- Height: 0.0000
- Length: 0.0000
- Weight: 1477.0000
- Width: 0.0000
Specifications
- Manufacturer: JET
- SKU: JT9-892301
- UPC: 731325282184
- Shipping Method: LTL Freight
- Weight: 1,477 lb
- Dimensions: 1 × 1 × 1 in
- Country of Origin: Taiwan
| Weight | 1477.0 lbs |
|---|---|
| Dimensions | 1.0 × 1.0 × 1.0 in |
| Brand | JET |
