Kalamazoo Industries 3HP 460V Three Phase 4” x 90” Grinder with Vacuum KS490V
$1,915.50Current price is: $1,915.50.
- 3PH amps: 3.6 amps
- 24-1/2″ long steel reversible and replaceable platen.
- Belt size: 4″ x 90″. All belt types are usable.
- Belt speed: 7200 SFPM.
Kalamazoo Industries 3HP 460V Three Phase 4” x 90” Grinder with Vacuum KS490V is a Kalamazoo Industries product in the Grinding & Sanding collection.
Product Details
- 3PH amps: 3.6 amps
- 24-1/2″ long steel reversible and replaceable platen.
- Belt size: 4″ x 90″. All belt types are usable.
- Belt speed: 7200 SFPM.
- Description
- Need to grind steel and cast iron quickly and keep it cool? The KS490V 4 x 90 inch grinder with vacuum is for fast and cool production grinding and sanding. Other features include a powerful 2HP 1PH or 3HP 3PH motor, 8″ OD x 4″ wide 70 duro serrated contact wheel, quick belt change, all steel construction, a built-in vacuum system, multiple grinding points, and full left to right movement.
- Designed to Do the Following
- Bevel
- Deburr
- Squaring up ends
- Rounding corners
- Flatwork
- Contouring
- Heavy metal removal
- Aggressive grinding
- Sharpening
- Production grinding
- Features
- Direct drive.
- Replaceable contact wheel specifications: 8″ OD x 3″ serrated 70 duro with sealed ball bearings.
- On/off switch.
- Spring belt tension.
- Quick-release belt tension lever.
- Easy belt tracking.
- Adjustable head stop.
- Removable steel platen guard.
- Adjustable steel work table.
- Adjustable belt grinder head.
- Hinged door on grinder head for quick belt and change.
- Multi-position horizontal through vertical.
- Steel base with built-in vacuum system.
- Replaceable filter.
- Specifications
- Motor: 3 HP 3 PH 230V or 460V
- Machine shipping dimensions: L 48″ x W 59″ x H 56″.
- Machine shipping weight: 325 lbs.
- Options
- KB49050 – 4 X 90 INCH ALUMINUM OXIDE SANDING BELTS
- KB49080 – 4 X 90 INCH ALUMINUM OXIDE SANDING BELTS
- KB490100 – 4 X 90 INCH ALUMINUM OXIDE SANDING BELTS
Specifications
- Manufacturer: Kalamazoo Industries
- SKU: KS490V (460V)
- Shipping Method: LTL Freight
- Weight: 325 lb
- Dimensions: 48 × 59 × 56 in
- Country of Origin: United States of America
- Warranty: 1 Year (Parts)
| Weight | 325.0 lbs |
|---|---|
| Dimensions | 48.0 × 59.0 × 56.0 in |
| Brand | Kalamazoo Industries |
