Revolution Machine Tools 40HP 440 Ton Hydraulic Precision Press Brake B-GENIUS 14-440

Revolution Machine Tools 40HP 440 Ton Hydraulic Precision Press Brake B-GENIUS 14-440 is a Revolution Machine Tools product in the Press Brakes collection.

Product Details

• Bending Force: 440 Tons
• Bending Length: 168”
• Distance Between Frames: 149”
• Length of Ram Stroke: 15”
• Description
• The B-GENIUS Series press brake features an automatic CNC crowning system for improved part quality, a servo driven back gauge system for increased speeds, and a 3D capable graphical control unit to simulate bending sequences and collision points.
• Benefits of RMT Press Brakes
• All RMT press brakes have been designed for high performance and enhanced with five main innovations to increase your productivity while decreasing your cost per part including: 1) A rigid mono-block frame constructed from mill certified high-yield steel for dependable performance; 2) Quality precision ram positioning accurate to within 0.0004 inch provided by dual cylinders and rams for stable ram motion; 3) A deeper throat allows you to use the full length of the machine to form more parts; 4) The increased daylight opening accommodates a larger range of parts; 5) More stroke length which provides additional flexibility and versatility.
• Built to Last
• The foundation of all RMT Press Brakes is a solid, mono-block frame made from mill-certified, high-yield steel. As a result, RMT Press Brakes perform accurately and reliably year after year. They’re so confident in their frames that they offer a 10-year warranty with their standard machines. Dual hydraulic cylinders located on either side of the ram provide faster approach speeds. The cylinders are synchronized to provide smooth motion resulting in precise ram positions to accuracies of 0.0004”.
• Bend Efficiently
• RMT Press Brakes can easily accommodate parts with deep bends and those that require long tooling, because of their open space design. RMT’s machines typically have deeper throat depths, larger daylight spaces and longer stroke lengths than any manufacturer on the market. They’ve also mounted the ram guides on the outside of the frame to maximize the distance between the side frames so that their Press Brakes can accommodate deep part flanges.
• Bend Accurately
• RMT machines are designed with state-of-the-art technologies that provide unparalleled accuracy and precision. This is the result of their world-class Research and Development departments that have been constantly perfecting their machines for decades, allowing them to consistently outperform competitor machines year after year.
• Bend Safely
• RMT Press Brakes were designed to maximize your safety with various features such as the ram-mounted AKAS-LC Safety Light Guard. Located at the bending level and based on the location of the punch tip, this system helps prevent injuries. The transmitter and receiver are fixed to the ram of the machine and form a laser-optical safety light grid that follows the ram or punch tip.
• What Makes RMT’s Press Brakes Revolutionary?
• Rigid mono-block frame of mill certified high-yield steel for minimum deflection under load resulting in more consistent performance. Synchronized dual cylinders and valves assure smooth, stable ram motion for high-quality precision ram positioning accurate to within 0.0004 inch. Deeper throat dimensions allow you to form more parts, the full length of the machine. Large daylight opening gives you versatility to handle larger range of parts. Extra stroke length also gives you more versatility.
• Features
• 7 Axis CNC: Y1, Y2 precision ram positioning X, R precision servo-driven back gauge Z1, Z2 Axes CNC motorized wave crowning
• Y1, Y2 precision ram positioning
• X, R precision servo-driven back gauge
• Z1, Z2 Axes
• CNC motorized wave crowning
• Large trio of value: Large open height Large stroke Large throat depth
• Large open height
• Large stroke
• Large throat depth
• Safety laser with manual F. AKAS II M -FPSC-B-C + safety covers with switch
• Delem DA-66T touch screen CNC control unit with 3D graphical visualization
• Clamping: American/European section-style box punch clamps (standard on 440 Ton and lower) American-only style punch clamp available at no charge on 440 Ton and lower
• American/European section-style box punch clamps (standard on 440 Ton and lower)
• American-only style punch clamp available at no charge on 440 Ton and lower
• Standard X Axis travel is 32.3” with third gauge step capable of gauging parts up to 41.7” with standard back gauge (most machines)
• Stable and fast AC servo motor-driven precision back gauge with linear guide and ball bearing system (X, R, Z1, Z2)
• Quick-set sliding front sheet support arms with full-length linear guide, tilting stop and T-slot (front gauge squaring, etc.)
• Protection covers (side and rear safety doors)
• Rear work light
• World-class hydraulic and electronic components that are easily replaceable (parts stocked by RMT or available off-the-shelf from your local supplier): Hydraulic blocks and valves (Hoerbiger) Electronics system (Siemens, Schneider, Mitsubishi)
• Hydraulic blocks and valves (Hoerbiger)
• Electronics system (Siemens, Schneider, Mitsubishi)
• Adjustable height suspension control unit arm
• High-yield plate construction
• Ability to accurately fade ram
• Stage bending
• Automatic bend sequence determination
• Automatic stretch length calculator for blank size determination
• Hydraulic Oil (up to 250 Ton machines)
• Specifications
• Daylight: 24.8”
• Throat Depth: 20.1”
• Bed Height 39.4”
• Bed Cap Width: 6”
• Number Sliding Front Support Arms: 2 Pcs.
• Motor Power: 40 HP
• Oil Tank Capacity: 106 Gal
• Rams Speeds Programmable Y-Axis Approach Speed: 57-283 I.P.M. Y-Axis Forming Speed: 0-21 I.P.M. Decompression: 0-21 I.P.M. Y-Axis Return Speed: 66-331 I.P.M.
• Y-Axis Approach Speed: 57-283 I.P.M.
• Y-Axis Forming Speed: 0-21 I.P.M.
• Decompression: 0-21 I.P.M.
• Y-Axis Return Speed: 66-331 I.P.M.
• Back Gauge System Programmable X-Axis Speed: 5-1181 I.P.M. X-Axis Travel: 40.2” 3rd Gaugeable Finger Position: 49.6” Standard R-Axis Max Speed: 5-283 I.P.M. R-Axis Travel: 10.2” Number Backgauge Finger Blocks: 2 Pcs.
• Programmable X-Axis Speed: 5-1181 I.P.M. X-Axis Travel: 40.2” 3rd Gaugeable Finger Position: 49.6”
• X-Axis Speed: 5-1181 I.P.M.
• X-Axis Travel: 40.2”
• 3rd Gaugeable Finger Position: 49.6”
• Standard R-Axis Max Speed: 5-283 I.P.M. R-Axis Travel: 10.2”
• R-Axis Max Speed: 5-283 I.P.M.
• R-Axis Travel: 10.2”
• Number Backgauge Finger Blocks: 2 Pcs.
• Machine Dimensions (L x W x H): 220” x 104” x 136”
• Approx. Weight: 60,060 lbs.
• Options
• Y-Axis Forming Speed Up to 350 Ton: 0-50 I.P.M.
• Z1-Z2 Axis Max. Speed: 5-3425 I.P.M.
• Bed Cap Width: 12”
• Extra daylight, stroke, and/or increased throat depths
• Safety laser: Motorized F. AKAS III M
• Light curtain: SICK C 4000 for tandem/trio/quad machines
• Adaptive bending sensors (angle measurement)
• Up to 14+ Axes available: X1, X2 Axes R1, R2 Axes X Prime (Delta X) Axis, +/- 5” stroke (10” total) X Axis = 40” external travel – back protection with light barrier X1, X2 Axes for light pole production Sheet follower with sliding guide – motorized height adjustment Front feeding system with supports Front feeding system with supports – pneumatic pushers
• X1, X2 Axes
• R1, R2 Axes
• X Prime (Delta X) Axis, +/- 5” stroke (10” total)
• X Axis = 40” external travel – back protection with light barrier
• X1, X2 Axes for light pole production
• Sheet follower with sliding guide – motorized height adjustment
• Front feeding system with supports
• Front feeding system with supports – pneumatic pushers
• Other CNC control units available: Delem DA-69T touch screen 2D/3D CNC control Cybelec ModEva 10S/12S/15S 3D with PC 1200 3D SW
• Delem DA-69T touch screen 2D/3D CNC control
• Cybelec ModEva 10S/12S/15S 3D with PC 1200 3D SW
• Clamping: Quick release clamping RMT hydraulic or mechanical clamping Wila or Wilson hydraulic or mechanical clamping
• Quick release clamping
• RMT hydraulic or mechanical clamping
• Wila or Wilson hydraulic or mechanical clamping
• Various tool options (RMT, Euro-American, Wila or Wilson)
• Extended back gauge stroke & back protection with light barrier
• Off-line software (V-Bend, Radbend, Profile-W)
• Tooling packages
• Multiple brake configurations available: Tandem configuration Trio configuration Quad configuration High tonnage flush floor models
• Tandem configuration
• Trio configuration
• Quad configuration
• High tonnage flush floor models
• Custom colors
• Strain gauge’s
• Material thickness measurement
• Keyed and interlocked frame

Specifications

• Manufacturer: Revolution Machine Tools
• SKU: B-GENIUS 14-440
• Shipping Method: Flatbed
• Weight: 60,260 lb
• Dimensions: 225 × 109 × 141 in
• Country of Origin: Turkey
• Warranty: 10 Years (Parts)
