Jet EVS-1440B Electronic Variable Speed Bench Lathe, 3HP 311440

Jet EVS-1440B Electronic Variable Speed Bench Lathe, 3HP 311440 is a JET product in the Lathes collection.

Product Details

• Standard Equipment
• 6" 3-Jaw Chuck
• Threading Dial Indictor
• Steady & Follow Rest
• LED Work Lamp
• The EVS-1440B is engineered to maximize your shop’s output. The D1 4 Spindle is precision ground for accuracy and supported by class 7 tapered roller bearings capable of a run out maximum of .0004’’. The spindle also features an apron-mounted actuation control and jog button for easy gear engagement and spindle inching. The two-speed gearbox allows operators to easily work at low speeds from 40 to 365 RPM, and at high speeds from 220 to 2,000 RPM. Additionally, the tailstock may be offset for turning taper. Meehanite castings retain their tolerance and remain rigid over many years of machining.
• 4-Position Carriage stop
• Chuck Guard
• Threading Dial Indicator
• Compound and cross slide have backlash elimination
• Electronic Chuck Key Docking Station
• Specification: Value
• Number of Spindle Speeds: Variable
• Swing Over Bed (In.): 14
• Distance Between Centers (In.): 40
• Swing Over Cross Slide (In.): 9-1/16
• Length of Gap (In.): 9-1/2
• Spindle Thread (In./TPI): 2 – 56
• Spindle Bore (In.): 1-1/2
• Spindle Taper: Morse #5
• Spindle Mount: D1-4
• Weight (Lbs.): 1584
• Spindle Taper with Sleeve: MT-5
• Range of Spindle Speeds (RPM): 40-2000
• Number of Longitudinal and Cross Feed Rates: 25
• Motor Power (HP): 3
• Range of Longitudinal Feeds (IPR): 0.0016-0.0460
• Range of Cross Feeds (IPR): 25
• Number of Inch Threads: 34
• Range of Inch Threads (TPI): 2-56
• Number of Metric Threads: 34
• Range of Metric Threads: 0.5-12
• Max Tool Size (In.): 3/4 x 3/4
• Compound Slide Travel (In.): 3-1/2
• Cross Slide Travel (In.): 7
• Motor (HP): 3 HP, 230V, 3-Phase
• Tailstock Spindle Travel (In.): 6-1/8
• Taper in Tailstock Spindle: MT-3
• Steady Rest Capacity (In.): 0.23-0.61 Copper Shaft ( Standard) 0.20-2.36 Bearing Roller(OP)
• Width of Bed (In.): 7.48
• Motor Phase: 3
• Motor Voltage (V.): 230
• Overall Dimensions (L x W x H) (In.): 68.5 x 28.3 x 50
• Prewired Voltage (V.): 230
• Drive: EVS
• Shipping Dimensions (L x W x H) (In.): 76 x 30 x 61
• Net Weight (Lbs.): 1320
• Gross Weight (Lbs): 1584
• Input Power: 230V 3ph
• Length: 68.5000
• Height: 50.0000
• Weight: 1584.0000
• Width: 28.3000

Specifications

• Manufacturer: JET
• SKU: JT9-311440
• UPC: 731325785777
• Shipping Method: LTL Freight
• Weight: 1,584 lb
• Dimensions: 68.5 × 28.3 × 50 in
• Country of Origin: Taiwan
