Powermatic PJ1696 16″ Jointer 7.5HP 3Ph 230/460V Helical Cutterhead
$8,972.60Current price is: $8,972.60.
- 20800Cuts Per Minute
- HelicalCutter Block
- 4Cutter Block Diameter
- 5200Cutter Block Speed
9 in stock
Overview
Powermatic PJ1696 16" Jointer 7.5HP 3Ph 230/460V Helical Cutterhead is documented as a Jointer from Powermatic Tools. The exact PM9-1791283 configuration is mapped to GT Machinery Solutions SKU JPW1791283. Recorded technical data includes horsepower: 7-1/2 HP, motor power: 37438, and motor voltage (v.): 230/460. Use the specification table and linked product literature to confirm electrical, capacity, dimensional, and installation requirements for project planning.
Technical Specifications
| Cuts Per Minute | 20800 |
|---|---|
| Cutter Block | Helical |
| Cutter Block Diameter | 4 |
| Cutter Block Speed | 5200 |
| Cutter Head Speed | 5200 RPM |
| Cutting Capacity (W x D) (In.) | 16 x 3/4 |
| Dust Collection Minimum CFM Required (CFM) | 800 |
| Dust Port Outside Diameter (In.) | 6 |
| Fence Positive Stops (Deg.) | 45, 90, -45 |
| Fence Size (L x H) (In.) | 47-1/4 x 5-1/4 |
| Fence Tilt (Deg.) | 45 Forward, 45 Backward |
| Horsepower | 7-1/2 HP |
| Infeed Table Length (In.) | 47-1/2 |
| Motor Phase | 3 |
| Motor Power | 37438 |
| Motor Voltage (V.) | 230/460 |
| Number of Knives | 56 Two Sided Inserts, 2 Rabbet |
| Outfeed Table Length (In.) | 47-1/4 |
| Phase | 3 |
| Prewired Voltage (V.) | 230 |
| Product Type | Jointer |
| Rabbeting Ledge (In.) | 5 x 24-1/2 |
| Recommended Circuit Size (Amps.) | 30/15 |
| Table Height from Floor (In.) | 37-1/2 |
| Table Size (L x W) (In.) | 96 x 16 |
| Voltage | 230/460V |
| Warranty | 5 Years |
| Weight | 1,400.000 lbs |
| Weight | 1400 lbs |
|---|---|
| Brand | Powermatic Tools |
