Baileigh MLD-1022 110V Single Phase Variable-Speed Mill Drill & Lathe Combination Machine BA9-1228216

Baileigh MLD-1022 110V Single Phase Variable-Speed Mill Drill & Lathe Combination Machine BA9-1228216 is a Baileigh Industrial product in the Lathes collection.

Product Details

• Cross Slide Travel: 4.5”
• Speed Range: 50-2250 rpm (variable)
• Tailstock Spindle Travel: 2”
• Width of Bed: 5.3”
• Description
• This combo mill drill lathe is ideal for small shops. Sturdily built with an MT-2 taper, the MLD-1022 offers all the features you’d want, including a DRO and independent motors.
• Features
• Runs on 110 volts. Just plug it into a standard outlet
• 2 independent 1HP motors (for the lathe and the mill) reduce wear and tear and give this combination machine a longer life.
• Adjustable lathe speed from 50 to 2,250 rpm with a DRO for precise cutting
• Steady rest and follow rest minimize vibrations for more accurate results
• Comes with 3-jaw and 4-jaw chucks to hold both square and rounded materials
• Built with robust MT-4 spindle taper on lathe & MT-2 on mill
• Yoke on stationary mill allows you to drill as on a traditional drill press
• Includes sheet metal stand, but you can also use this mill drill lathe on your benchtop
• Precision-ground and hardened ways ensure long life and years of high-quality machining
• Specifications
• Distance Between Centers: 22”
• Distance Spindle to Column (Max): 6.5”
• Spindle Bore: 1.1”
• Spindle Distance to Table (Max): 8.375”
• Spindle Taper: MT4
• Mill Taper: MT2
• Swing Over Bed: 9.75”
• Swing Over Cross Slide: 5.7”
• Range of Inch Threads (Min/Max): 8” / 56”
• Range of Longitudinal Feeds (Min/Max): 0.003 / 0.008 IPR
• Range of Metric Threads (Min/Max): 0.4” / 3.5”
• Electrical Requirements: 110V Single Phase 1HP
• Machine Dims: 69” x 44” x 55”
• Approx Weight: 450 lbs

Specifications

• Manufacturer: Baileigh Industrial
• SKU: BA9-1228216
• UPC: 19907766858
• Shipping Method: LTL Freight
• Weight: 580 lb
• Dimensions: 69 × 44 × 55 in
• Country of Origin: China
