Baileigh Variable Speed Drill Press DP-1500VS

Baileigh Variable Speed Drill Press DP-1500VS is a Baileigh Industrial product in the Drill Presses collection.

Product Details

• Variable-speed inverter-driven head
• 3-speed power down feed
• Auto reverse tapping feature
• Digital RPM readout
• 20" Drill Press Machine Baileigh model DP-1500VS heavy duty drill press comes standard with power feed and a quality auto reversing tap feature. This is a quality made machine using only the best quality castings and base metals to support rigidity when drilling at maximum capacity with the power down feed. The base and drill table is made from a heavy casting that has oversized T-Slots for secure clamping of a vise or fixture. This variable speed drill press has an inverter driven head whose quill speed can be properly adjusted to each different drill size that really will extend tooling life. Adjustments to the speed can be done by a speed potentiometer dial, noting the RPM is displayed on the digital read out. Additional standard features of this quality floor type drill press are a safety guard with limit switch, a powerful coolant system, and a bright halogen light.
• Table Size: 22" x 18.5"
• Quill Diameter: 2.95"
• Quill Feed: .0078", .004", .002" per rev.
• Spindle Nose to Table: 22.75"
• Spindle Nose to Base: 40.75"
• Spindle Speed High: 245 – 2000 rpm
• Spindle Speed Low: 65 – 540 rpm
• Spindle Taper: MT 4
• Table Slot: .625"
• Tapping Capacity: .937"
• Main Motor: 2 hp
• Drill Capacity Cast Iron: 1.75"
• Drill Capacity Steel: 1.5"
• Power: 220V Single Phase
• Shipping Weight: 902 lbs
• Spindle Travel: 5.9"
• Column Diameter: 4.52"
• Base Dimensions LxW: 27" x 19"
• Shipping Dimensions: 40" x 25" x 83"

Specifications

• Manufacturer: Baileigh Industrial
• SKU: BA9-1002923
• UPC: 731325404845
• Shipping Method: LTL Freight
• Weight: 855 lb
• Dimensions: 40 × 25 × 83 in
• Country of Origin: Taiwan
