Concept Easy 250 Solid Platen Case Clamp

Overview

Concept Easy 250 Solid Platen Case Clamp is documented as a model-specific catalog item from Gannomat. The exact 0750-B250 configuration is mapped to GT Machinery Solutions SKU GN0750-B250. Recorded technical data includes weight: 2,300.000 lbs. Use the specification table and linked product literature to confirm electrical, capacity, dimensional, and installation requirements for project planning.

Key Features

• Sturdy stress-free steel frame construction
• Steel bar side pressure beam construction with solid platen surface
• Continuous left-side counter pressure surface and solid floor
• Selector knob for variable pressing force anywhere between 300kg – 2200kg
• Pressing force of the pressure beam is digitally regulated by frequency changer for wear-free torque transfer
• Travel/pressing velocity is 5mm-10mm-25mm/second by selector knob
• Simple operation by directional push buttons
• Adjustable clamping cycle time 0-30 minutes (programmable to seconds or hours), with automatic opening
• Optional working height 2500mm (98-27/64")
• Working/loading height (without legs) 200mm (7-7/8")

Technical Specifications
